ColliHigh NWSF-1AT temperature transmitter Manual
The ColliHigh JQBW-8 temperature transmitter is a low‑power, LCD‑display device that measures particle concentration and provides 4‑20 mA, 0‑10 V, or RS‑485 output signals. It is intended for use in air purification, food processing, hospitals, and similar environments.
The manual describes the technical parameters, wiring and installation steps, user interface operation, alarm settings, communication configuration, and calibration tables. It also lists the physical dimensions, power consumption, and environmental limits of the device. This manual is written in Japanese.
Collihigh NWSF-1AT specifications
| Supply voltage | DC24 V (22‑26 V) |
|---|---|
| Measurement range | 0‑8.8 k particles per dry |
| Output signal (current) | 4‑20 mA |
| Output signal (voltage) | 0‑10 V |
| Output signal (RS‑485) | RS‑485 |
| Output impedance | 250 Ω |
| Power consumption | 42 mA |
| Accuracy | ±10 % |
| Operating temperature | -10 °C to 60 °C |
| Storage temperature | -20 °C to 60 °C |
| Dimensions (module) | 54 mm × 45 mm (approx.) |
| Dimensions (housing) | 180 mm × 130 mm × S3 mm |
| Weight | 370 g |
