AMPROBE INSTRUMENTS ACD-6 Pro ACD-6 TRMS Pro 1000 A Digital Clamp-ons Manual
The ACD-6 Pro and ACD-6 TRMS Pro are digital clamp‑on meters designed for basic electrical measurements. They support AC and DC voltage, current, resistance, and include features such as auto/manual ranging, data hold, and a large LCD display. The meters can accommodate conductors up to 1.77 in (45 mm) in diameter and meet safety CAT III 600 V requirements.
Key features include a built‑in diode test, audible continuity, relative zero mode, and an auto power‑off function. Optional accessories such as line splitters, high‑current clamp‑on attachments, and thermocouple temperature adapters are available, and a carrying case is supplied with the product.
Amprobe ACD-6 specifications
| AC Current Range | 400 A – 1000 A |
|---|---|
| DC Voltage Range | 0.004 V – 600 V |
| AC Voltage Range | 4 V – 600 V |
| Resistance Range | 0 Ω – 40 MΩ |
| Capacitance Range | 500 nF – 3000 pF |
| Frequency Range | 10 Hz – 100 kHz |
| Input Impedance | 10 MΩ |
| Weight | 190 g |
| Maximum Conductor Diameter | 45 mm |
| Safety Category | CAT III 600 V |
Source: AMPROBE INSTRUMENTS ACD-6 Pro 1000 A Digital Clamp-Ons Digital Clamp-Ons
All Amprobe ACD-6 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What is the maximum AC current measurement range of the ACD-6 Pro?
The ACD-6 Pro can measure AC current up to 1000 A.
From: AMPROBE INSTRUMENTS ACD-6 Pro 1000 A Digital Clamp-Ons Digital Clamp-Ons
What safety category does the ACD-6 Pro meet?
It complies with safety category CAT III 600 V.
From: AMPROBE INSTRUMENTS ACD-6 Pro 1000 A Digital Clamp-Ons Digital Clamp-Ons
What safety category does the ACD-6 Pro meet?
It meets the CAT III 600 V safety category.
From: AMPROBE INSTRUMENTS ACD-6 Pro ACD-6 TRMS Pro 1000 A Digital Clamp-ons Manual
What is the maximum AC current measurement range?
The meter can measure up to 1000 A AC.
From: AMPROBE INSTRUMENTS ACD-6 Pro ACD-6 TRMS Pro 1000 A Digital Clamp-ons Manual
