ALINX AX7035 Artix-7 FPGA Development Board User Manual
The ALINX AX7035 is a versatile FPGA development platform based on the Xilinx Artix-7 series chip (XC7A35T). It features high-speed data processing capabilities with 2Gbit DDR3 SDRAM and includes a wide range of peripheral interfaces such as HDMI input/output, Gigabit Ethernet, USB 2.0, UART, SD card slot, and expansion ports.
Read onlineALINX AX7035 specifications
| FPGA Chip Model | XC7A35T-2FGG484I |
|---|---|
| DDR3 Memory Capacity | 2Gbit (256MB) |
| Data Bit Width | 16 bits |
| DDR Clock Frequency | 400Mhz |
| System Bandwidth | 12.8Gb/s |
| QSPI Flash Capacity | 128Mbit |
| Ethernet Speed | 10/100/1000 Mbps |
| USB Speed | 480Mb/s |
| Board Dimensions | 130mm x 90mm |
Source: ALINX AX7035 Artix-7 FPGA Development Board User Manual
All ALINX AX7035 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
What FPGA chip does the AX7035 use?
It uses the Xilinx Artix-7 series FPGA chip XC7A35T-2FGG484I.
From: ALINX AX7035 Artix-7 FPGA Development Board User Manual
What is the capacity of the onboard DDR3 memory?
The board includes a large-capacity 2Gbit (256MB) high-speed DDR3 SDRAM.
From: ALINX AX7035 Artix-7 FPGA Development Board User Manual
What is the FPGA chip model used in the AX7035?
The board uses the Xilinx Artix-7 series FPGA chip, specifically model XC7A35T-2FGG484I.
From: Alinx AX7035 Artix-7 FPGA Development Platform User Manual
What is the capacity of the onboard DDR3 memory?
The development board includes a 2Gbit (256MB) high-speed DDR3 SDRAM.
From: Alinx AX7035 Artix-7 FPGA Development Platform User Manual
