The XM 7S electronic drum sound module user manual provides setup, operation, hardware installation, parameter settings, troubleshooting and warranty…
The XM 7S is an electronic drum sound module that offers multiple drum kits, MIDI connectivity, and adjustable parameters for volume, sensitivity, and tone. It is designed for drummers of all skill levels and can be connected to any electronic drum kit.
The manual covers product features, safety precautions, hardware installation, component descriptions, basic operation, tone parameter tables, troubleshooting steps, and how to restore factory settings. It also includes wiring diagrams for inputs, outputs, and MIDI ports. This manual is written in Chinese.
| Maximum PAD support | 16 |
|---|---|
| Power supply | AC6V |
| MIDI ports | IN and OUT |
| MIDI ports | IN and OUT |
| Display | LCD panel |
| Power switch | POWER button |
With the unit powered off, hold the four panel buttons, press the power button with the left‑hand ring finger until “REC” appears on the screen, then release the buttons.
Push the POWER key upward to switch the unit on.
