Pioneer XMp3 Car Kit Installation Guide

This document is an installation guide for the XMp3™ Radio Car Kit, providing instructions on how to install and use the product.

Brand: XM
Category: Car Speakers
Document type: Installation Guide
Language: English
Pages: 32
File format: PDF
File size: 1.9 MB
Published: 06 July, 2012
Updated: 28 September, 2023
Model: XMP3
MD5 checksum: 3FC7563766F5EF3F79CD06BBA9C84853
PDF: Pioneer XMp3 Car Kit Installation Guide PDF

About this manual

This guide provides step-by-step instructions for setting up the Pioneer XMp3 Radio Car Kit. It covers planning the installation location, mounting the car antenna on the vehicle exterior, and installing either a swivel or vent mount inside the dashboard.

The document details how to route the antenna cable through weather seals and door jams without pinching it, connect the audio cable, and configure the radio settings such as finding an FM frequency and setting line out levels. It also includes troubleshooting tips for common issues.

What's inside

Introduction
Remote control functions
Vehicle Installation
Mounting the XM car antenna
Installing the swivel or vent mount
Connecting your XMp3 radio
Turning on your XMp3 radio
Troubleshooting

Specifications

Car Cradle Dimensions	57 mm (W) X 81.6 mm (H) X 45.2 mm (D)
XM Car Antenna Cable Length	23 feet
Audio Cable Length	1 meter with standard 3.5 mm stereo plug on each end
Remote Battery Type	CR2032

Frequently asked questions

How long does the adhesive for the swivel mount need to cure?

You must let the adhesive cure for 24 hours before attaching the XM cradle and radio.

What is the minimum temperature required during swivel mount installation?

The air temperature must be at least 60°F (15°C) during installation.

What happens if I use an unauthorized distributor?

There are no warranties, express or implied, including merchantability and fitness for a particular purpose.
