The manual explains operation, adjustment, and maintenance of the KD7351 electric gate synchronous controller.
The KD7351 is a low‑cost, high‑performance electric gate synchronous controller that uses a single‑chip microcontroller (WE7351) as its core. It provides adjustable opening/closing time and current, supports continuous and timed work modes, and consumes only 12 W of power, making it compact and reliable for integration into gate systems.
The user manual details parameter settings, adjustment methods, operating modes, wiring connections, safety precautions, and troubleshooting steps, allowing installers and technicians to configure and maintain the controller safely and efficiently. This manual is written in Chinese.
| Dimensions | 9 × 5 × 12 cm |
|---|
It measures 9 × 5 × 12 cm.
