User manual for the Weimike KU8806 AC servo controller, covering setup, parameters, wiring and safety.
The KU8806 is an AC servo controller that uses a micro‑controller as the main unit and supports position control via external sensors. It can store up to five parameter groups, each defining motor settings and delay times, and features low power consumption (15 W) with a compact size of 160 × 80 × 125 mm.
The manual provides detailed instructions for parameter configuration, wiring connections, operation modes, and safety precautions. It also lists technical specifications such as input voltage, power rating, dimensions, and weight, helping users install, adjust, and maintain the controller safely and efficiently. This manual is written in Chinese.
| Input Voltage | AC 380 V 50 Hz |
|---|---|
| Dimensions | 160 mm × 80 mm × 125 mm |
| Parameter 2 Range | 0 ~ 99 (0 ~ 1.98 s) |
The controller measures 160 mm × 80 mm × 125 mm.
It operates on AC 380 V at 50 Hz.
