Key facts
- Manuals
- 4
- Languages
- ZH
- Last added
- 2012-03-15
Featured Beijing威姆科焊接器材 manuals
Weimke KD7806 Digital Welding Synch Controller User Manual
The KD7806 is a micro‑computer‑controlled welding synch controller that manages six program stages—pre‑pressure, pre‑heat, welding, tempering, hold and pause—by digitally adjusting timing and current. It uses a low‑power VE7306 MCU, consumes about 15 W, and offers modular design for easy integration into welding machines.
The manual provides technical specifications, detailed installation steps, wiring diagrams for SCRs and external devices, and operating instructions including program selection, current and frequency adjustment, and power‑factor tuning. Safety notes and recommended protective devices are also included. This manual is written in Chinese.
Covers: Technical Specifications · Installation Method · SCR Wiring Method · Operation Instructions · Power Factor Adjustment · Safety and Protective Devices
Wemco KD7351 Electric Gate Synchronous Controller User Manual
The KD7351 is a low‑cost, high‑performance electric gate synchronous controller that uses a single‑chip microcontroller (WE7351) as its core. It provides adjustable opening/closing time and current, supports continuous and timed work modes, and consumes only 12 W of power, making it compact and reliable for integration into gate systems.
The user manual details parameter settings, adjustment methods, operating modes, wiring connections, safety precautions, and troubleshooting steps, allowing installers and technicians to configure and maintain the controller safely and efficiently. This manual is written in Chinese.
Covers: Parameter Settings · Adjustment Method · Operating Modes · Technical Specifications · Installation and Wiring · Safety Instructions
WEMCO KD7302/7318/7320/7323 Spot Welding Synchro Controller Manual
This document describes the functions and installation of the WEMCO KD7302/7318/7320/7323 micro‑computer spot welding synchro controller. It includes wiring diagrams, parameter adjustment ranges, and safety notes for proper use.
The guide also lists technical specifications such as input voltage, power rating, weight, and control ranges, and provides troubleshooting steps and maintenance advice to keep the controller operating reliably. This manual is written in Chinese.
Covers: Parameter Settings · Operation Instructions · Wiring Diagram · Troubleshooting · Technical Specifications · Safety Information
Weimike KU8806 AC Servo Controller Manual
The KU8806 is an AC servo controller that uses a micro‑controller as the main unit and supports position control via external sensors. It can store up to five parameter groups, each defining motor settings and delay times, and features low power consumption (15 W) with a compact size of 160 × 80 × 125 mm.
The manual provides detailed instructions for parameter configuration, wiring connections, operation modes, and safety precautions. It also lists technical specifications such as input voltage, power rating, dimensions, and weight, helping users install, adjust, and maintain the controller safely and efficiently. This manual is written in Chinese.
Covers: Parameter Settings · Parameter Description · Operation Instructions · Safety Precautions · Wiring Connections · Technical Specifications
Latest Beijing威姆科焊接器材 manuals
Weimke KD7806 Digital Welding Synch Controller User Manual
User Manual 3 pages · 85 KB · ZHUser manual for the Weimke KD7806 digital welding synch controller, covering specifications, installation, wiring and operation.
Wemco KD7351 Electric Gate Synchronous Controller User Manual
User Manual 2 pages · 91 KB · ZHThe manual explains operation, adjustment, and maintenance of the KD7351 electric gate synchronous controller.
WEMCO KD7302/7318/7320/7323 Spot Welding Synchro Controller Manual
User Manual 3 pages · 88 KB · ZHThe manual provides operation, wiring, parameter settings, and troubleshooting for WEMCO KD7302/7318/7320/7323 spot welding synchro controllers.
Weimike KU8806 AC Servo Controller Manual
User Manual 3 pages · 84 KB · ZHUser manual for the Weimike KU8806 AC servo controller, covering setup, parameters, wiring and safety.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Beijing威姆科焊接器材 manuals
How many program segments does the KD7806 controller have?
The KD7806 controller provides six program segments.
From: Weimke KD7806 Digital Welding Synch Controller User Manual
What is the maximum control current the controller can handle?
It can handle a maximum control current of 300 A.
From: Weimke KD7806 Digital Welding Synch Controller User Manual
What are the physical dimensions of the KD7351 controller?
It measures 9 × 5 × 12 cm.
From: Wemco KD7351 Electric Gate Synchronous Controller User Manual
What is the input voltage for the controller?
The controller operates on AC 380V 50Hz.
From: WEMCO KD7302/7318/7320/7323 Spot Welding Synchro Controller Manual
What are the physical dimensions of the controller?
The controller measures 160 mm × 80 mm × 125 mm.
What is the required input voltage for the controller?
It operates on AC 380 V at 50 Hz.
