The WAGO Process Industrial Solutions leaflet describes the WAGO‑I/O‑SYSTEM, JUMPFLEX and TOPJOB S products for modular, flexible automation in harsh…
This leaflet presents WAGO’s process‑industrial solution portfolio, focusing on the modular WAGO‑I/O‑SYSTEM platform, the JUMPFLEX® analog signal isolation modules, and the TOPJOB S rail‑mounted wiring terminals. It highlights the system’s independence from field‑bus standards, extensive international certifications, compact design, and high reliability for demanding applications such as oil‑field, power‑plant and renewable‑energy installations.
The document also provides guidance on selecting the appropriate wiring terminals, details the technical specifications of the modules (temperature ranges, voltage ratings, channel counts), and outlines WAGO’s quality‑assurance measures and certifications that ensure performance in harsh environments. This manual is written in Chinese.
| WAGO‑I/O‑SYSTEM module thickness | 12 mm |
|---|---|
| Maximum channels per node | 16 |
| JUMPFLEX 857 series width | 6.0 mm |
| JUMPFLEX 857 temperature range | -25 °C to +70 °C |
| JUMPFLEX 2857 temperature range | -40 °C to +70 °C |
| Voltage rating for measurement terminals | 1500 VDC (IEC) / 1000 VDC (UL) |
| Current rating for measurement terminals | 30 A |
The JUMPFLEX 857 series operates from –25 °C up to +70 °C.
A WAGO‑I/O‑SYSTEM node can provide up to 16 channels.
The module width is only 6.0 mm, saving space in distribution cabinets.
