The Tektronix DPO3000 series digital phosphor oscilloscope manual provides specifications, operation instructions, and advanced serial‑bus analysis features.
This manual describes the DPO3000 series digital phosphor oscilloscopes, covering bandwidth options from 100 MHz to 500 MHz, up to 2.5 GS/s sampling, 5 M‑point record length, and a 9‑inch WVGA display. It details the Wave Inspector® control functions, vertical and horizontal system settings, and the extensive serial‑bus trigger and decode capabilities for I²C, SPI, CAN, LIN, and RS‑232/422/485/UART.
The document also explains how to use the built‑in search, marker, and zoom/scroll controls to locate events quickly, and lists optional modules (DPO3AUTO, DPO3EMBD, DPO3COMP, DPO3VID) that extend functionality for automotive, embedded, computer, and video applications. This manual is written in Chinese.
| Maximum Sample Rate | 2.5 GS/s (all channels) |
|---|---|
| Record Length | 5 M points |
| Maximum Waveform Capture Rate | 50,000 wfm/s |
| Display Size | 9‑inch WVGA (800 × 480) |
| Vertical Resolution | 8 bits (11 bits Hi‑Res option) |
| Input Channels | 2‑ or 4‑channel models |
Wave Inspector® offers zoom, scroll, playback, and marker functions that simplify waveform navigation and analysis.
