The SONBEST SM5395B user manual provides setup, connection options, specifications, and safety information for the outdoor wind speed, temperature, humidity…
The SM5395B is an outdoor integrated sensor that measures wind speed, temperature, humidity and illumination. It uses an industrial‑standard USB interface for easy connection to PLC, DCS and other instruments, and can be customized with various output protocols such as RS232, RS485, CAN, 4‑20 mA, DC0‑5 V/10 V, ZIGBEE, LORA, WIFI, GPRS and NB‑IOT.
Technical parameters are listed, including wireless signal LORA, frequency 410‑439 MHz, transmit power 5‑20 dBm, default baud rate 9600 8 N 1, and operating ranges of –30 °C to 85 °C and 5 %RH to 90 %RH. The manual also contains typical application examples, a delivery list, and a disclaimer. This manual is written in Chinese.
| Wireless signal | LORA |
|---|---|
| Wireless frequency | 410~439MHz |
| Rate level | 0~5 |
| Transmit power | 5~20dBm |
| Communication interface | USB |
| Default baud rate | 9600 8 N 1 |
| Power supply | DC5V 1A |
| Operating temperature | -30~85℃ |
| Operating humidity | 5%RH~90%RH |
| Supported output interfaces | RS232, RS485, CAN, 4‑20 mA, DC0‑5 V/10 V, ZIGBEE, LORA, WIFI, GPRS, NB‑IOT |
The sensor uses a USB interface by default and can be customized to support RS232, RS485, CAN, 4‑20 mA, DC0‑5 V/10 V, ZIGBEE, LORA, WIFI, GPRS and NB‑IOT.
The device operates from –30 °C to 85 °C and in humidity from 5 %RH to 90 %RH.
The default baud rate is 9600 8 N 1.
