The Rousun RS-1224 manual provides specifications, wiring diagram, and operating instructions for the dual‑channel non‑contact DC current controller.
About this manual
The RS-1224 is a dual‑channel non‑contact DC current controller designed for 4~20 mA input and output signals. It offers high accuracy (<0.2 %) and operates over a wide temperature range.
This manual details the technical specifications, pin assignments, wiring connections, and performance parameters such as accuracy, temperature limits, and power supply requirements. It also includes a pin‑out table and wiring diagram to aid installation and troubleshooting. This manual is written in Chinese.
What's inside
- Technical Specifications
- Accuracy
- Input and Output Signals
- Operating Temperature
- Power Supply
- Pin Assignment
- Wiring Diagram
