Raynen RS3E V1.0 Servo Drive Hardware Manual

About this manual

This document is the hardware manual for the Raynen RS3E V1.0 servo drive. It introduces the product information, installation procedures, and wiring details for this high cost-performance AC servo product. The manual covers safety precautions, product specifications, installation requirements, and terminal definitions. This manual is written in Chinese.

What's inside

• Safety Precautions
• Product Information
• Installation
• Wiring
• Terminal Definitions
• Anti-interference Countermeasures

Frequently asked questions

What is the power range supported by this servo drive series?

The RS3E series supports a power range of 0 to 3 kW.

How long must one wait after cutting power before performing wiring or maintenance?

You must wait at least the time specified on the warning label after cutting power.
