Raynen RS3P1 Servo Drive Hardware Manual

This manual covers the installation, wiring, terminal definitions, and anti-interference measures for the Raynen RS3P1 servo drive.

Brand: Raynen
Category: Motor
Document type: User Manual
Language: Chinese
Pages: 41
File format: PDF
File size: 2.1 MB
Published: 15 October, 2026
Updated: 15 October, 2026
MD5 checksum: AA45D2935E394283DEEC67D6B8F68342
PDF: Raynen RS3P1 Servo Drive Hardware Manual PDF

About this manual

The Raynen RS3P1 servo drive is a simplified version of the RS3 series, featuring a power range of 0 to 2 kW. It supports the Modbus communication protocol and includes functions such as inertia identification and automatic gain adjustment. The drive is designed for use in automated equipment within industries like electronic manufacturing, robotics, packaging, and machine tools. This manual is written in Chinese.

What's inside

Safety Precautions
Product Information
Installation
Wiring
Terminal Definitions
Anti-interference Measures

Specifications

Power Range	0 ~ 2 kW

Frequently asked questions

What communication protocol does the RS3P1 support?

The RS3P1 series supports the Modbus communication protocol.

Where can I download the electronic version of this manual?

You can download the PDF file from the Raynen Technology official website.

Download PDF (2.1 MB)
