The Pioneer SL1612A digital camera user manual provides safety guidelines, operation steps, shooting modes, and technical specifications.
This manual introduces the Pioneer SL1612A digital camera, covering safety precautions, basic handling, and the functions of its 3.0" TFT LCD screen. It explains how to power the camera, insert the battery, and navigate the menu for shooting photos, videos, and using special modes such as panorama and selfie.
The document also details the camera's technical specifications, supported storage media, lens characteristics, and troubleshooting tips for common issues like power problems, focus errors, and memory card errors. This manual is written in Chinese.
| Image sensor | 1/2.33" CCD (16 MP) |
|---|---|
| Maximum image resolution | 4608 × 3456 pixels |
| LCD screen | 3.0" TFT, 460 K pixels |
| Internal memory | 32 MB (≈11 MB usable for images) |
| Supported storage cards | SD/SDHC up to 32 GB |
| File formats | DCF, JPEG (EXIF 2.2), DPOF, Motion‑JPEG (AVI), HD720p/30fps |
| Lens | 12.5× optical zoom, 3.0‑5.9 aperture, 4.2‑52.5 mm focal length |
| Focus range | Macro 0.05 m, Super‑macro 0.01 m, Standard 0.2 m‑∞ |
| Digital zoom | 4× (shooting), 12× (playback) |
| Power source | Rechargeable Li‑ion battery, 3.7 V |
| Dimensions | ≈100.8 mm × 58.4 mm × 19.8 mm |
| Weight | ≈149 g (without battery and card) |
Check that the battery is correctly inserted and fully charged; a missing or depleted battery prevents power-up.
Adjust the LCD brightness in the menu settings as instructed.
Recording stops automatically when a video reaches 4 GB or about 25 minutes in length.
