Preliminary specification for the NUC1xx series of 32-bit ARM Cortex-M0 microcontrollers featuring up to 50MHz operation and various communication interfaces.
This document is a preliminary specification sheet for the NUC1xx series of 32-bit microcontrollers based on the ARM Cortex-M0 core. The series includes sub-families such as NUC100, NUC101, NUC120, NUC130, and NUC140, designed for industrial control applications requiring rich communication interfaces.
The datasheet details the features of each sub-family, including memory sizes (Flash and SRAM), peripheral capabilities like UART, SPI, I2C, USB, CAN, and PWM timers. It also provides pin configuration tables, block diagrams, functional descriptions of internal modules, electrical characteristics, and package definitions. This manual is written in Chinese.
The NUC101 series can run at a maximum external clock speed of 50MHz.
The device includes built-in Flash storage ranging from 32K to 128K bytes.
The device operates with a wide voltage range from 2.5V to 5.5V.
