This document provides an overview of the Nuvoton NuMicro family of microcontrollers, which includes product lines powered by ARM Cortex-M0, Cortex-M4, ARM7/ARM9, and 8051 cores. The family is designed for a wide range of applications including industrial control, consumer products, and embedded network systems, offering a high performance-to-cost ratio.
The catalog details specific product series such as the NuMicro M0, M4, Mini51, and M051 series, listing their key features, operating conditions, and potential applications. It also includes a comprehensive list of available package dimensions for various models, ranging from QFN33 to LQFP176.
| Operating Voltage (M0/M4) | 2.5V ~ 5.5V |
|---|---|
| Operating Temperature (M0/M4) | -40°C ~ 105°C |
| Operating Voltage (Nano100) | 1.8V ~ 3.6V |
| Max Frequency (M051) | up to 50 MHz |
| Max Frequency (Mini51) | up to 24 MHz |
| Flash Memory (M051) | 8/16/32/64 Kbytes |
| SRAM (M051) | 4 Kbytes |
| Flash Loader Memory (M051) | 4 Kbytes |
| Flash Memory (Mini51) | 4/8/16/32 Kbytes |
| SRAM (Mini51) | 2/4 Kbytes |
| Flash Loader Memory (Mini51) | 2 Kbytes |
| ESD Immunity | 8KV |
The NuMicro family is ideal for use in consumer products, industrial control, embedded network control, energy and power system, motor control, health care and battery powered devices.
The M051 series is operable at temperatures ranging from -40°C to +85°C or +105°C.
