This user manual provides installation and configuration instructions for the Mercury MR904B dual-WAN internet router designed for small businesses and…
The Mercury MR904B is a high-performance broadband router specifically designed to meet the needs of small enterprises and internet cafes. It features two WAN ports for simultaneous data forwarding, enhancing packet forwarding capabilities and allowing for ISP load balancing to improve access speeds.
The device includes built-in security features such as attack protection against DoS, IP spoofing, and virus attacks like Nimda and Blaster. It supports Quality of Service (QoS) based on IP or port to manage bandwidth and connection limits per user, preventing resource overuse by P2P applications. This manual is written in Chinese.
| WAN Ports | 2 x 10/100M adaptive RJ45 ports (Auto MDI/MDIX) |
|---|---|
| LAN Ports | 3 x 10/100M adaptive RJ45 ports (Auto MDI/MDIX) |
| Dimensions | 294mm x 180mm x 44mm |
| Operating Temperature | 0ºC to 40ºC |
| Power Input | 100-240VAC, 50/60Hz |
| Maximum Power Consumption | 5.6W |
The router should be placed horizontally, away from heat-generating devices, and in a clean, dry place.
You can enable the IP and MAC address binding function to force a one-to-one correspondence between IP and MAC addresses.
Yes, it supports ISP load balance control to effectively utilize the dual WAN ports and improve website access speed.
