Comprehensive guide for using the Loongson 1B development board, covering hardware, Linux setup, bootloader, and application examples.
The Loongson 1B Development Board User Manual provides detailed information on the board's hardware resources, including CPU, memory, interfaces, and peripherals. It also explains how to set up a Linux development environment on a host PC, compile the PMON bootloader and Linux kernel, and flash them onto the board.
Additional sections cover application porting, a series of development experiments (e.g., ADC, PWM, networking), and extensive appendices with tool usage instructions such as Minicom, EJTAG, and NFS configuration. This manual is written in Chinese.
| CPU | Loongson 1B, 200‑233 MHz (configurable to 266 MHz) |
|---|---|
| Memory | 64 MB DDR2 SDRAM (K4T51163QI) |
| Flash Storage | 512 KB SPI Flash (W25X40BVSSIG) + 128 MB NAND Flash |
| LCD | 4.3‑inch LCD, up to 480×272 resolution |
| USB | 4× USB 2.0 HOST ports |
| CAN Bus | 2× standard CAN interfaces |
The PMON prompt is shown as "PMON>" before commands.
The UART operates at up to 115200 bps.
Ubuntu 10.04 is used for the host development environment.
