The Lincoln QuickLub Systems Owner’s and Maintenance Manual provides operation, installation, programming, troubleshooting, and spare parts information for…
The Lincoln QuickLub System is a 12 or 24‑volt electric pump system that delivers lubricant through progressive‑metering valves and cross‑porting. It can be configured with 1‑, 2‑, 4‑, 8‑, or 15‑liter reservoirs and operates on less than 5 amps of DC power. The system includes a proximity switch that monitors valve cycles and ensures proper lubrication of each bearing point.
The manual is organized into sections covering system operation, components, pump mounting and wiring, purging and testing, programming, troubleshooting, and spare‑parts recommendations. Detailed part numbers and specifications for pumps, valves, switches, hoses, and other components are provided to aid installation, maintenance, and repair.
| Operating Voltage | 12 or 24 V |
|---|---|
| Maximum Power Consumption | <5 A DC |
| Reservoir Sizes | 1 L, 2 L, 4 L, 8 L, 15 L |
| Maximum System Pressure | 350 bar |
| Feedline Hose Rating | 4,000 psi |
| Operating Temperature Range | -30 °C to +100 °C |
It operates on either 12 V or 24 V electric power.
The feedline hose is rated for up to 4,000 psi.
Reservoirs are available in 1, 2, 4, 8, and 15 liter sizes.
The proximity switch part number is 519‑34339.
