Leroy‑Somer 4970 en ATEX High‑efficiency Induction Motors Technical Catalogue

This technical catalogue lists Leroy‑Somer 4970 en ATEX‑rated high‑efficiency three‑phase induction motors, their construction, electrical data, dimensions…

Brand: Leroy-Somer
Category: Motor
Document type: Product Leaflet
Language: English
Pages: 140
File format: PDF
File size: 9.7 MB
Published: 03 October, 2026
Updated: 03 October, 2026
MD5 checksum: 60207B9547FC7B2952C400832FF92124
PDF: Leroy‑Somer 4970 en ATEX High‑efficiency Induction Motors Technical Catalogue PDF

About this manual

The catalogue presents the ATEX‑certified high‑efficiency induction motors from Leroy‑Somer, covering models suitable for explosive gas (ATEX GAS Zones 1 & 2) and dust (ATEX DUST Zones 21 & 22) atmospheres. It includes general information, quality commitments, certification details, and definitions of hazardous zones.

Detailed sections describe motor construction (cast‑iron and aluminium frames), electrical characteristics (power, speed, voltage, IP rating), dimensions, optional mechanical and electrical options, as well as installation, wiring, and maintenance procedures. Appendices provide a configurator and product availability information.

What's inside

General Information
Certification
Environment
Construction
Operation
Installation and Maintenance
Appendices

Specifications

Rated power	18.5 kW
Speed	1500 min‑1
Voltage	230/400 V
Frame size	4P

Frequently asked questions

Which ATEX zones are covered by these motors?

The motors are certified for ATEX GAS Zones 1 & 2 and ATEX DUST Zones 21 & 22.
