Official service manual for Lenovo ThinkCentre desktop models 1732‑7559, covering safety, troubleshooting, and FRU replacement.
This Service Manual provides detailed service and reference information for Lenovo ThinkCentre desktop computers listed on the cover. It is intended for trained service technicians familiar with Lenovo products and includes safety guidelines, troubleshooting procedures, and a complete FRU part‑number listing.
The manual contains chapters on safety, general information, troubleshooting, setup utility usage, FRU replacement instructions, and additional service information such as BIOS flashing and power‑management features. Physical specifications and environmental limits are also listed.
| Width | 545.2 mm (21.46 inches) |
|---|---|
| Height | 414.3 mm (16.31 inches) |
| Depth | 81 mm (3.19 inches) |
| Weight (max shipped) | 8.4 kg (18.52 lb) |
| Low‑range input voltage | 100 V ac – 127 V ac, 50‑60 Hz |
Read all caution and danger statements in the manual before performing any instructions and follow the general safety rules such as keeping the work area clean and using proper lifting techniques.
FRU part numbers are listed in the manual and are also available online at Lenovo’s support website.
Locate the hard‑disk drive, remove the cover, disconnect the drive, replace it with a new unit, and reinstall the cover as described in the FRU replacement section.
Use the Setup Utility program to launch the BIOS update procedure, following the steps outlined in the Additional Service Information chapter.
