The Leica TS06plus total station provides high‑precision angle and distance measurement, Bluetooth and USB connectivity, and extensive surveying functions…
Leica TS06plus is a high‑accuracy total station featuring a robust angle measurement system (2″‑7″ accuracy) and a long‑range distance system (up to 3500 m with prism, >1000 m with PinPoint). It includes Bluetooth and USB communication, a large 3.3‑inch graphical display, and an all‑digital keypad for efficient field operation.
The instrument is designed for harsh environments, operating from –20 °C to +50 °C (customizable to –35 °C), with IP55 protection, a 5.1 kg weight, and up to 30 hours of battery life. It supports a wide range of surveying applications such as building layout, road and tunnel measurement, and water‑power monitoring, with many localized Chinese software modules. This manual is written in Chinese.
| Angle measurement accuracy | 2″, 5″, 7″ |
|---|---|
| Prism distance range | 3500 m |
| No‑prism distance (PinPoint R500) | >500 m |
| No‑prism distance (PinPoint R1000) | >1000 m |
| Battery type | Lithium |
| Weight (instrument + base) | 5.1 kg |
| Operating temperature range | -20 °C to +50 °C (customizable to -35 °C) |
| Ingress protection | IP55 |
| Display resolution | 160 × 288 pixels |
| Communication interfaces | Standard USB, Mini USB, Bluetooth (150 m) |
The TS06plus provides angle accuracy of 2″, 5″ or 7″ depending on the selected mode.
The instrument supports standard USB, Mini USB, and Bluetooth communication (up to 150 m).
It works from –20 °C to +50 °C, and a custom low‑temperature version can operate down to –35 °C.
