Leica BLK360 is a lightweight, portable 3‑D laser scanner with Wi‑Fi, infrared camera and HDR panorama, delivering full scans in 3 minutes.
The Leica BLK360 mini laser scanner combines high‑speed WFD laser scanning, HDR panoramic imaging and an infrared camera in a compact, 1 kg device. It operates with a single button, offers Wi‑Fi remote control via an app, and stores data for up to 40 stations on its built‑in rechargeable battery.
The system integrates with Leica Cyclone Register 360 software for automatic point‑cloud stitching, publishing in multiple formats (E57, TruView, JetStream) and seamless workflow with BIM tools such as AutoCAD and Revit. It is suited for geology, cultural‑heritage documentation, construction, film production, BIM and law‑enforcement applications. This manual is written in Chinese.
| Height | 165 mm |
|---|---|
| Diameter | 100 mm |
| Weight | 1 kg |
| Scan range | 0.6 – 60 m |
| Scan rate | 360,000 points/second |
| Distance accuracy | 4 mm @ 10 m / 7 mm @ 20 m |
| Point‑cloud accuracy | 6 mm @ 10 m / 8 mm @ 20 m |
| Laser safety class | Class 1 (IEC 60825‑1:2014) |
| Laser wavelength | 830 nm |
| Field of view | 360° × 300° |
| Battery type | Built‑in rechargeable Li‑ion (Leica GEB212) |
| Battery capacity (stations) | Typical >40 stations per charge |
| Memory capacity | Stores >100 stations |
| Operating temperature | +5 °C – +40 °C |
| Ingress protection | IP54 |
A full 360° scan, photo capture and thermal imaging can be finished in about 3 minutes.
The device weighs approximately 1 kilogram.
It can scan objects up to 60 meters away.
