Inspur FS5900/6500/6600 Basic Function Configuration Manual

About this manual

This document serves as a configuration guide for the Inspur FS5900, FS6500, and FS6600 Fibre Channel (FC) switches. It details the product positioning, hardware characteristics, and technical specifications for each model in the series.

The guide provides step-by-step instructions for initial configuration, including setting the management IP, changing the switch name, and configuring ISL Trunking. It also explains how to manage zones using both GUI and CLI, upgrade the firmware, and lists common commands for system monitoring and troubleshooting. This manual is written in Chinese.

What's inside

• Product Positioning
• Hardware Characteristics
• Technical Specifications
• Initialization Configuration
• Zone Management
• Firmware Upgrade
• Common Commands
• Terms and Abbreviations

Frequently asked questions

What is the default number of active ports on the FS5900?

The FS5900 defaults to activating 8 ports out of its available 8, 16, or 24-port configurations.

What is the maximum power consumption for the FS6500?

The FS6500 can consume up to 80W when all 24 ports operate at 16Gb.

What is the maximum bandwidth for an ISL trunk on the FS6600?

Each ISL trunk on the FS6600 can provide up to 128 Gbps of bandwidth.
