Infineon XMC1000 Microcontroller Tooling Guide

The Infineon XMC1000 Tooling Guide explains boot mode selection, ASC loader, and ASC programmer usage for the XMC1000 microcontroller series.

Brand: Infineon
Category: Other Electronics
Document type: Application Note
Language: English
Pages: 40
File format: PDF
File size: 2.2 MB
Published: 08 October, 2026
Updated: 08 October, 2026
MD5 checksum: 8EBCF46689A7693D23F7DEA8F24DD544
PDF: Infineon XMC1000 Microcontroller Tooling Guide PDF

About this manual

This guide provides detailed information on the boot mode index (BMI) used to select the start‑up mode of XMC1000 devices, including default settings and how to program the BMI value. It also describes the ASC loader and ASC programmer tools, their communication protocols, and required pin configurations.

The document includes use‑case tables, pin assignment charts, and step‑by‑step instructions for using the demonstrator software and reference documents for further development of applications based on the XMC1000 family.

What's inside

Boot Mode Index for Booting Up
ASC Loader
ASC Programmer
Boot Mode Use Cases
Programming / Debugging Pin
Description of the Boot Modes
Reference Documents

Specifications

Boot Mode Index memory location	0x10000E00
Default boot mode at factory	ASC BSL
BMI value for ASC Bootstrap Loader mode	0xFFC0
UART pins for ASC BSL (Half Duplex)	P0.14 (RXD), P0.14 (TXD)
Request BMI installation routine address	0x00000108

Frequently asked questions

How is the boot mode determined on XMC1000 devices?

The boot mode is selected by the Boot Mode Index (BMI) value stored in flash configuration sector 0.

Which pins are used for UART communication in ASC BSL mode?

In ASC BSL Half‑Duplex mode the UART uses P0.14 for both RXD and TXD (alternatively P1.3 can be used).

How can the BMI value be changed after the device is programmed?

The BMI value can be changed by calling the Request BMI installation routine located at ROM address 0x00000108 from your application code.
