Honeywell 13mm Pressure Transducer User Manual

The Honeywell 13mm pressure transducer manual provides specifications, wiring, installation and performance data for 13C and 13U models.

Brand: Honeywell
Category: Other
Document type: User Manual
Language: Chinese
Pages: 6
File format: PDF
File size: 322 KB
Published: 13 November, 2011
Updated: 30 September, 2026
MD5 checksum: 31CB7A611FD61093D98B0E6B240EFA15
PDF: Honeywell 13mm Pressure Transducer User Manual PDF

About this manual

This manual describes the Honeywell 13mm pressure transducer series, including the 13C and 13U variants. It covers mechanical dimensions, mounting options, and the electrical characteristics needed for proper integration.

Key sections provide pressure range tables, output voltage characteristics, temperature limits, supply requirements, and wiring diagrams. Installation guidelines and calibration procedures are also included to help users achieve accurate measurements. This manual is written in Chinese.

What's inside

Specifications
Electrical Characteristics
Pressure Range
Temperature Limits
Supply Voltage and Current
Wiring Diagram
Installation
Calibration Procedure

Specifications

Pressure range (13C 0500P)	0‑500 psi
Pressure range (13C 5000P)	0‑5000 psi
Output voltage (full scale)	98 mV/°C
Operating temperature	-40 °C to +125 °C
Supply voltage	5 V DC
Supply current	1.0 mA

Frequently asked questions

What supply voltage is required for the 13mm transducer?

The transducer operates from a 5 V DC supply (some versions also list 10 V DC).

What are the allowable ambient temperature limits?

The device can be used from –40 °C up to +125 °C.
