Chinese user manual for the Holip HLP-A series variable frequency drive covering installation, wiring, operation, and maintenance.
The Holip HLP-A series is a high‑performance, multifunctional variable frequency drive. This manual provides detailed instructions for safe installation, wiring, configuration, and operation of the drive, as well as maintenance and troubleshooting procedures.
Key safety warnings are highlighted throughout, including the need to cut power before wiring, proper grounding, and restrictions on connecting external devices to the output terminals. Technical specifications, control methods, and communication options are also listed for reference. This manual is written in Chinese.
| Input voltage | 380V ±15% (220V ±15% for low‑voltage version) |
|---|---|
| Frequency control range | 0.10 ~ 400.00 Hz |
| Control method | SPWM |
| Communication interface | RS‑485 |
| Operating temperature | -10 °C ~ 40 °C |
| Relative humidity | 0 % ~ 95 % (non‑condensing) |
No. The output side must not have contactors, capacitors, or similar switching devices, as they can cause faults or damage the drive.
An air‑break circuit breaker (NFB) must be installed between the power source and the R.S.T input terminals, and the power line should be isolated and grounded.
The drive can operate from 0.10 Hz up to 400.00 Hz.
