HLP-P series frequency converter instruction manual, introduces the safety precautions for frequency converter, product standard specifications, storage and installation, wiring, digital operator instructions, trial run, function overview table, function description, maintenance, maintenance, fault information and troubleshooting methods, peripheral facilities selection and configuration, etc.
This manual covers the safe use, installation, wiring, and configuration of the Holip HLP-P series speed governor. It includes detailed safety precautions, product specifications, and step‑by‑step installation procedures to ensure proper setup and reliable operation.
The document also describes the digital operator panel, function list, maintenance routines, and troubleshooting methods. Technical data such as input/output ratings, frequency range, and communication protocols are provided for reference. This manual is written in Chinese.
| Model | HLPP001143B |
|---|---|
| Input Voltage | 3PH 380V 50Hz |
| Output Voltage | 3PH 380V 24A 11kW |
| Frequency Range | 0.1‑400 Hz |
The device requires a three‑phase 380 V, 50 Hz input.
It delivers a three‑phase 380 V output at 24 A, equivalent to 11 kW.
The governor can be set between 0.1 Hz and 400 Hz.
Safety usage precautions are listed in the second chapter of the manual under "安全使用注意事項".
