The Heli Shi HS series servo drive user manual provides safety guidelines, installation, wiring, operation, troubleshooting and maintenance instructions.
This manual covers the complete lifecycle of the Heli Shi HS series servo drive, starting with product overview, safety precautions, and installation requirements. Detailed sections describe the operation panel, wiring diagrams, trial run procedures, and normal operation modes.
Later chapters address status monitoring, bus communication settings (Modbus, CAN), fault codes, and recommended maintenance practices to ensure reliable long‑term performance in industrial applications. This manual is written in Chinese.
| Rated Power | 200 W |
|---|---|
| Input Voltage | 220 V single‑phase, 50/60 Hz |
The ground terminal must be connected to a reliable ground with resistance below 4 Ω.
Ensure the power supply is turned off for at least 15 minutes and that the capacitors have fully discharged before any work on the main circuit terminals.
