Featured HeLiShi manuals
Heli Shi HS Series Servo Drive User Manual
This manual covers the complete lifecycle of the Heli Shi HS series servo drive, starting with product overview, safety precautions, and installation requirements. Detailed sections describe the operation panel, wiring diagrams, trial run procedures, and normal operation modes.
Later chapters address status monitoring, bus communication settings (Modbus, CAN), fault codes, and recommended maintenance practices to ensure reliable long‑term performance in industrial applications. This manual is written in Chinese.
Covers: Product Overview and Installation · Operation Panel Usage · Wiring · Trial Run · Operation · Status Monitoring and Bus Communication
HeLiShi TS Series Digital AC Servo Drive User Manual
The TS series digital AC servo drives from HeLiShi are high‑performance, high‑reliability drives for servo motors used in CNC machines, machining centers, and large‑scale equipment. They employ a TI DSP core and advanced digital motor control algorithms to precisely control position, speed, and torque of permanent‑magnet synchronous motors.
The manual provides safety guidelines, unpacking checks, installation requirements, detailed wiring diagrams, operation‑panel functions, trial‑run procedures, control‑mode selections, parameter settings, and fault‑diagnosis instructions. Appendices list full‑closed‑loop I/O wiring and parameter tables. This manual is written in Chinese.
Covers: Product Overview and Installation · Wiring · Operation Panel Usage · Trial Run · Control Modes · Parameters and Functions
Latest HeLiShi manuals
Heli Shi HS Series Servo Drive User Manual
User Manual 150 pages · 5.8 MB · ZHThe Heli Shi HS series servo drive user manual provides safety guidelines, installation, wiring, operation, troubleshooting and maintenance instructions.
HeLiShi TS Series Digital AC Servo Drive User Manual
User Manual 87 pages · 5.2 MB · ZHThis manual covers installation, wiring, operation, parameters, and troubleshooting for HeLiShi TS series digital AC servo drives.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in HeLiShi manuals
How should the ground terminal be connected?
The ground terminal must be connected to a reliable ground with resistance below 4 Ω.
What should be done before performing wiring on the main circuit terminals?
Ensure the power supply is turned off for at least 15 minutes and that the capacitors have fully discharged before any work on the main circuit terminals.
How can a fault alarm be cleared?
Disable the enable signal, then clear the alarm; otherwise the drive may restart unexpectedly.
