The HDS Series outdoor stainless steel enclosure datasheet provides dimensions, materials, finishes, IP rating, and accessory options.
The HDS Series offers painted stainless steel outdoor enclosures built from 430 stainless steel with a RAL7035w powder‑coated finish. The bodies are 1.5 mm thick, doors are 1.2 mm galvanized steel, and the units achieve an IP66 rating for protection against dust and water.
The sheet lists multiple size variants (e.g., HDS GP 3020, 4020, 5020) with their width, depth, useful area, and weight. It also details optional accessories such as mounting plates, gland plates, door stays, pole‑fitting sets, and specialized locks. This manual is written in Chinese.
| Material | Stainless Steel 430 (EN 10088‑1.4016) |
|---|---|
| Surface Finishing | RAL7035w powder coating |
| Body Thickness | 1.5 mm |
| Door Material | Galvanized Steel (EN 10346 DX51D+Z) 1.2 mm |
| IP Rating | IP66 |
| Weight (kg) – HDS GP 3020 | 0.6 |
| Width (mm) – HDS GP 3020 | 300 |
| Depth (mm) – HDS GP 3020 | 200 |
The enclosure body is made of stainless steel grade 430.
The enclosures have an IP66 rating.
They are finished with a RAL7035w powder coating.
The body thickness is 1.5 mm.
