Featured HDS manuals
HDS Series Outdoor Stainless Steel Enclosure Datasheet
The HDS Series offers painted stainless steel outdoor enclosures built from 430 stainless steel with a RAL7035w powder‑coated finish. The bodies are 1.5 mm thick, doors are 1.2 mm galvanized steel, and the units achieve an IP66 rating for protection against dust and water.
The sheet lists multiple size variants (e.g., HDS GP 3020, 4020, 5020) with their width, depth, useful area, and weight. It also details optional accessories such as mounting plates, gland plates, door stays, pole‑fitting sets, and specialized locks. This manual is written in Chinese.
Covers: Characteristics · Material · Surface Finishing · Thickness · IP Rating · Dimensions
HDS Carbon Quick Start Guide
The guide provides an overview of the HDS Carbon’s main functions, including touchscreen operation, cursor keys, zoom, menu navigation, waypoint creation, and power controls. It explains how to access and customize panels, hide menus, and adjust display settings such as brightness and night mode.
Additional sections describe sonar-specific features like StructureScan® frequencies, fishing mode presets, and how to view sonar history. Instructions are included for creating and saving waypoints, using cursor assist mode, and managing data overlays and split screens.
Covers: Overview of Key Functions · Power and Brightness Controls · Home Page and Panel Navigation · Menu and Page Management · Waypoint Creation and MOB Saving · Cursor Assist Mode
OWON HDS1022M Handheld Digital Storage Oscilloscope User Manual
This manual introduces the OWON HDS series handheld digital storage oscilloscope, its components, safety information, and general inspection procedures. It includes product certification details, a list of supplied accessories, and guidelines for handling and storage.
The guide covers detailed operating instructions such as connecting the device, using the front panel controls, setting vertical and horizontal systems, trigger configuration, measurement functions (voltage, current, resistance, capacitance, diode testing), and advanced features like automatic measurement, waveform storage, and data transmission. Maintenance, battery charging, and troubleshooting sections are also provided. This manual is written in Chinese.
Covers: Product Certification · Safety Information · General Inspection · Oscilloscope Connection · Initial Use of Oscilloscope · Vertical/Horizontal System Settings
Latest HDS manuals
HDS Series Outdoor Stainless Steel Enclosure Datasheet
Datasheet 2 pages · 380 KB · ZHThe HDS Series outdoor stainless steel enclosure datasheet provides dimensions, materials, finishes, IP rating, and accessory options.
HDS Carbon Quick Start Guide
Quick Start Guide 8 pages · 7.2 MB · ENQuick start guide for the HDS Carbon device, covering key functions, navigation, settings, and usage instructions.
OWON HDS1022M Handheld Digital Storage Oscilloscope User Manual
User Manual 76 pages · 1.2 MB · ZHThe OWON HDS1022M handheld digital storage oscilloscope user manual provides setup, operation, safety, and maintenance instructions.
