Quick reference guide for the Hamilton C3 ventilator covering basics, setup, testing, patient ventilation, monitoring, alarms and control parameters.
The Hamilton C3 Quick Start Guide provides a concise reference for using the C3 ventilator with adult and pediatric patients. It outlines basic concepts, step‑by‑step setup, testing and calibration procedures, and guidance for patient ventilation and data monitoring.
The guide also describes the device’s user interface, including screen functions, alarm handling, key controls, and the available connectors (RS‑232, USB, RJ‑45, power and oxygen ports). It includes a glossary of control‑parameter terminology to help users understand settings and alarms. This manual is written in Chinese.
| RS-232 connector | for external monitoring |
|---|---|
| RJ-45 Ethernet connector | |
| DC power connector | |
| AC power socket |
Press the alarm mute key to silence the alarm for 2 minutes; press it again to cancel the mute.
Touch the “i” icon on the screen to open the alarm help screen and view alarm history.
The C3 provides RS‑232, USB, and RJ‑45 Ethernet connectors for external monitoring and data communication.
Press the rich‑oxygen key to deliver 100% O₂ for 2 minutes; press the key again to stop the delivery.
