Step‑by‑step instructions, safety warnings, required tools and adjustment tips for installing the Garmin LVS34 LiveScope Plus transducer kit on a vessel.
This guide provides important safety information for installing the Garmin LVS34 LiveScope Plus transducer kit, including the need for protective eye goggles, hearing protection and a dust mask when drilling or cutting. It also explains that the installation must be performed by qualified marine installers to avoid damage to the vessel or the equipment.
The document lists the required tools (drill, 17 mm wrench, torque wrench, sealant, etc.) and details the mounting procedure: positioning the bracket, drilling mounting holes, securing the transducer with bolts tightened to 20 N·m, routing the cable, and adjusting the angle and depth. It also notes the need to update the Garmin chartplotter software and provides a link to an installation support video. This manual is written in Chinese.
| Maximum operating speed | 19 km/h (12 mph) |
|---|---|
| Bolt torque | 20 N·m (15 ft‑lb) |
| Recommended drill size for positioning holes | 4 mm (5/32 inch) |
| Cable pass‑through hole size | 32 mm (1¼ inch) hole saw |
You must wear protective eye goggles, hearing protection and a dust mask when drilling, cutting or grinding.
The transducer’s performance is limited when operating faster than 19 km/h (12 mph).
The bolts should be tightened to 20 N·m (15 ft‑lb).
Yes, you must update the Garmin chartplotter software; instructions are available on support.garmin.com.
