The Fujitsu ETERNUS JX40 S2 is a direct‑attached storage subsystem offering up to 192 TB capacity and hot‑plug components for PRIMERGY servers.
The Fujitsu ETERNUS JX40 S2 Storage Subsystem provides a passive direct server‑attached solution that expands the storage of Fujitsu PRIMERGY servers via a 12 Gbit/s SAS connection. It supports mixed disk configurations, hot‑plug drives and power supplies, and can be managed through the standard ServerView Suite.
Technical details include up to four enclosures, a maximum of 96 SAS/SSD drives, 192 TB total capacity, and compliance with multiple safety and EMC standards. The unit is rack‑mountable (19"), operates between 10‑40 °C, and offers 92 % power‑supply efficiency (80 PLUS Gold).
| Maximum storage capacity | 192 TB |
|---|---|
| Maximum number of disk drives | 96 SAS disks and SSDs |
| Maximum number of enclosures | 4 |
| Power‑supply efficiency | 92 % (80 PLUS Gold) |
| Operating temperature (non‑operating) | 10 °C – 40 °C (50 °F – 104 °F) |
| Power voltage | AC 100‑120 V / AC 200‑240 V |
The subsystem can store up to 192 TB of data.
Up to four drive enclosures can be installed.
Yes, the redundant hot‑plug power‑supply units support hot replacement.
