The Extreme Networks C5 series is a stackable Gigabit Ethernet switch with high‑power PoE, up to 8‑unit stacking and extensive security features.
The C5 series from Extreme Networks provides scalable, high‑performance Gigabit Ethernet switching for demanding business environments. It supports 10/100/1000 ports, optional 10 GE uplinks, and full L2/L3/L4 packet processing, with built‑in IPv4/IPv6 routing and policy‑based automation.
Key features include 802.3at high‑power PoE on all ports, up to eight switches stackable into a single virtual switch, advanced QoS with eight priority queues per port, and comprehensive security such as 802.1X, ACLs, and role‑based policies. The devices are covered by a lifetime warranty and meet multiple industry standards.
| Switching Capacity (single switch) | 48 Gbps (35.7 Mpps) |
|---|---|
| Stacking Capacity (single switch) | 128 Gbps (95.2 Mpps) |
| Maximum PoE Power per Port | up to 30 W (IEEE 802.3at) |
| Dimensions (H × W × D) | 4.4 cm × 44.1 cm × 36.85 cm |
| Power Consumption (non‑PoE 24‑port) | 65 W |
Up to eight C5 switches can be interconnected in a single virtual stack.
When stacked, the C5 provides up to 1,024 Gbps (761.8 Mpps) of stacking capacity.
