Featured Extreme Networks manuals
Extreme Networks XR600 Router Quick Reference Guide
The XR600 router enables branch office and remote office networking with two WAN ports, four LAN ports, a console port and two USB ports. LED indicators on the top, front panel and near each port show power, connection and activity status.
The guide details power connection using the supplied 54 V DC adapter, installation options (desktop, wall‑mount, rack), safety precautions, reset procedure and regulatory compliance statements for multiple regions. This manual is written in Chinese.
Covers: Product Overview · Hardware Components · LED Indicator Descriptions · Power Connection · WAN and LAN Ports · USB Ports
Extreme Networks ERS 3600 Ethernet Routing Switch Datasheet
The ERS 3600 series provides a flexible, high‑capacity Ethernet routing platform optimized for branch offices and small wiring closets. It supports static and dynamic IP routing, Fabric Attach, and a stackable architecture up to eight units (400 ports) with up to 192 Gbps virtual backplane bandwidth.
Available in 24‑port and 48‑port models, the switch offers PoE/PoE+ options, 10 GbE uplink and stacking ports, and a rich feature set including QoS‑aware stacking, advanced security (802.1X, ACLs), and extensive Layer 3 services such as RIP, DHCPv6 Guard, and IPv6 features. This manual is written in Chinese.
Covers: Highlights · Benefits · Features and Functions · Product Overview · Specifications · System Compatibility
Extreme Networks AP3865e Outdoor Access Point Data Sheet
The AP3865e outdoor access point is designed for harsh environments such as warehouses, production floors, parks and stadiums. It supports dual‑band 2.4 GHz and 5 GHz operation, 802.11ac performance, dynamic RF management, mesh networking and PoE+ power.
Key features include 3×3:3 MIMO, up to 1.75 Gbps wireless throughput, 75 000 packets‑per‑second wired forwarding, role‑based security, and an IP67/NEMA 6 environmental rating for temperature ranges from –40 °C to +60 °C. This manual is written in Chinese.
Covers: Product Overview · Technical Specifications · Adaptive RF Management · Environmental Ratings · Warranty and Support
Latest Extreme Networks manuals
Extreme Networks XR600 Router Quick Reference Guide
Quick Start Guide 2 pages · 492 KB · ZHThe Extreme Networks XR600 router quick reference guide provides an overview, hardware components, LED indicators, power, ports, installation and safety…
Extreme Networks ERS 3600 Ethernet Routing Switch Datasheet
Datasheet 6 pages · 340 KB · ZHThe ERS 3600 Ethernet routing switch from Extreme Networks offers high‑performance, non‑blocking, stackable switching with PoE/PoE+ and 10 GbE uplinks.
Extreme Networks AP3865e Outdoor Access Point Data Sheet
Datasheet 4 pages · 567 KB · ZHThe AP3865e is a high‑performance outdoor Wi‑Fi access point with dual‑band 2.4 GHz/5 GHz support, up to 1.75 Gbps throughput and IP67 rating.
Which document do I need?
Quick Start Guide
The shortest path to a working setup, usually only a few pages.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Extreme Networks manuals
How many WAN ports does the XR600 have?
The XR600 has two WAN ports, labeled WAN0/ETH0 and WAN1/ETH1.
What power adapter is required for the XR600?
Use the supplied 54 V DC adapter rated at 1.67 A (90.18 W) with an input range of 100‑240 V AC.
What power method does the AP3865e support?
It can be powered via 802.3at PoE (PoE+).
From: Extreme Networks AP3865e Outdoor Access Point Data Sheet
What is the maximum wireless throughput of the AP3865e?
The access point provides up to 1.75 Gbps wireless throughput per AP.
From: Extreme Networks AP3865e Outdoor Access Point Data Sheet
