Technical specifications for Epson EB-1485Fi and EB-1480Fi ultra short‑throw laser projectors.
This document provides detailed specifications for the Epson EB-1485Fi and EB-1480Fi projectors, covering mechanical dimensions, optical performance, interfaces, environmental requirements, and optional accessories such as wall mounts and touch units.
It also includes information on interactive features, supported monitor resolutions, wireless connectivity, and recommended installation guidelines for single or multiple projector setups.
| Dimensions (EB-1485Fi) | 458 × 223.5 × 450 mm |
|---|---|
| Weight (EB-1485Fi, projector only) | ≈ 9.3 kg |
| Light source output power | Up to 104.5 W |
| Brightness (Normal mode) | 5,000 lm |
| Contrast ratio | Over 2,500,000:1 |
| Resolution (pixel count) | 1,049,088 dots |
| Power consumption (100‑120 V) | 381 W |
| Recommended gap for multiple projectors | At least 1,200 mm |
The EB-1485Fi measures 458 mm wide, 223.5 mm high, and 450 mm deep (excluding the raised section and cable cover).
It provides a brightness of 5,000 lumens in the normal light‑source mode.
A minimum separation of 1,200 mm is required between projectors to ensure proper cooling.
