Detailed specifications, service life guarantees and pricing for Elstein MaxLife FSM ceramic infrared heaters.
The Elstein MaxLife FSM series are ceramic infrared radiators designed for industrial heating applications. They offer a wide power range from 60 W to 1 000 W, operating temperatures up to 750 °C and a service life of up to 35 000 hours, with a 20 000‑hour (3 year) warranty.
The document provides dimensional data, surface‑rating values, weight, voltage, and price lists for each model variant (FSM, FSM/2, FSM/4 and their thermocouple versions). It also includes marketing arguments for resellers, recommended customer groups, and a comparison with competing FSR copies.
| Operating temperature | up to 750 °C (max 750 °C) |
|---|---|
| Wattage range | 60 W to 1 000 W |
| Dimensions (FSM) | 245 mm × 60 mm |
| Surface rating | up to 64 kW/m² |
| Operating voltage | 230 V |
| Weight (FSM) | 220 g |
The series covers power ratings from 60 W up to 1 000 W across the different model sizes.
The standard FSM panel measures 245 mm in length and 60 mm in width.
