DJI RoboMaster Robot Technical Specification and Referee System Installation Guide

About this manual

This document serves as a comprehensive technical specification guide for teams participating in the RoboMaster competition. It outlines strict requirements for robot design, manufacturing, and usage to ensure compliance with competition standards. The manual covers various aspects of the robot, including energy systems, communication devices, visual features, armor stickers, and specific designs for Hero, Engineering, Infantry, Air, and Sentinel robots. This manual is written in Chinese.

What's inside

• General Technical Specifications
• Robot Finished Product Usage Rules
• Hero Robot Specifications
• Engineering Robot Specifications
• Infantry Robot Specifications
• Air Robot Specifications
• Sentinel Robot Specifications
• Referee System Installation Overview
• Main Control Module Installation
• Power Management Module Installation

Specifications

Frequently asked questions

What is the input voltage requirement for the power management module?

The input voltage must be between 22V and 26V.

What are the maximum continuous loads for the Chassis and Gimbal interfaces?

Each single path has a maximum continuous load of 10A.

What wire gauge is required for connections between chassis-related circuit boards?

Wire gauge must be less than or equal to 24AWG.
