The CAP3 series ATSE is a PC‑level automatic transfer switch for 50/60 Hz AC230/240 V or AC400/415 V, rated 16 A‑4000 A, offering millisecond switching and…
The CAP3 series automatic transfer switch (ATSE) from Changshu Switchgear is designed for critical power supply applications such as data centers, hospitals, airports and industrial plants. It operates on 50/60 Hz AC systems, supports voltages of AC230/240 V and AC400/415 V, and handles currents from 16 A up to 4000 A, providing continuous and reliable power by quickly switching between sources.
The guide covers product overview, normal operating conditions, mechanical structure, detailed technical specifications, functional features, model designations, installation clearances, wiring diagrams, conductor sizing, torque requirements and ordering instructions. It also describes the smart communication options (DeviceNet, Profibus‑DP, CAN, TCP/IP, WIFI) and cloud connectivity. This manual is written in Chinese.
| Rated Voltage | AC230/240 V (2‑pole) / AC400/415 V (3‑/4‑pole) |
|---|---|
| Rated Current Range | 16 A – 4000 A |
| Switching Time | <50 ms for 125/250/630/1600 frames, <75 ms for 4000 frame |
It supports AC230/240 V for 2‑pole units and AC400/415 V for 3‑ or 4‑pole units.
The contact switching time is less than 50 ms for 125, 250, 630 and 1600 frames, and less than 75 ms for the 4000 frame.
The device can communicate via DeviceNet, Profibus‑DP, CAN, TCP/IP and WIFI, and can be connected to cloud platforms.
Write the order as “CAP3‑200/4iHⅢF” followed by the quantity.
