Asus P5K EPU Motherboard Maintenance and Repair Guide

About this manual

This document serves as an introductory guide to understanding motherboards, covering their status in a computer system, classification methods, and key components. It details the structure and function of various motherboard types and chipsets.

The text specifically references the Asus P5K EPU motherboard as a typical example to illustrate concepts. It provides a comprehensive overview of CPU socket types (such as Socket 370, 462, 478, AM2, and T) and structural standards (AT, Baby-AT, ATX, Micro ATX, NLX, and BTX). This manual is written in Chinese.

What's inside

• Introduction to Motherboards
• Motherboard Classification by CPU Socket
• Motherboard Classification by Structure
• Main Chips and Components
• Expansion Slots and Interfaces
• Common Markings and Architecture
• Typical Motherboard Examples
