Analog Devices LT8336 DC/DC Converter Datasheet

The Analog Devices LT8336 is a low I Q, synchronous step-up DC/DC converter with Silent Switcher architecture and optional spread spectrum frequency modulation.

Brand: Analog Devices
Category: DC/DC Converter
Document type: Datasheet
Language: English
Pages: 24
File format: PDF
File size: 1.9 MB
Published: 13 October, 2026
Updated: 13 October, 2026
MD5 checksum: 13468B05457AC555085E7D1500164814
PDF: Analog Devices LT8336 DC/DC Converter Datasheet PDF

About this manual

The LT8336 is a low quiescent current, synchronous step-up DC/DC converter featuring Silent Switcher architecture to minimize EMI emissions. It includes integrated 40V, 2.5A power switches and operates at a fixed switching frequency programmable between 300kHz and 3MHz.

What's inside

Features
Typical Application
Applications
Pin Configuration
Absolute Maximum Ratings
Order Information
Electrical Characteristics
Typical Performance Characteristics

Specifications

Input Voltage Range	2.7V to 40V
Output Current	2.5A
Switching Frequency Range	300kHz to 3MHz
Quiescent Current (Shutdown)	0.3µA
Quiescent Current (Burst Mode)	4µA
Package Type	16-Lead LQFN (3mm × 3mm)

Frequently asked questions

What is the maximum input voltage for the LT8336?

The device supports a wide input voltage range up to 40V.

Does the LT8336 support PassThru operation?

Yes, it features 100% duty cycle capability for the synchronous MOSFET in PassThru operation.

Is the LT8336 qualified for automotive applications?

Yes, it is AEC-Q100 qualified for automotive applications.
