Agilent N5700 Series DC Power Supply Quick Reference Guide

About this manual

This guide introduces the Agilent N5700 series system DC power supply, a universal switched‑mode supply with multiple voltage and current ratings. It describes the front‑panel controls, rear‑panel connectors, and the built‑in remote interfaces (GPIB, USB, LAN).

Key sections cover safety precautions, installation of the unit, connection of power and load cables, output voltage sensing, parallel/serial operation, protection functions, output on/off control, analog programming of voltage and current, and configuration of the remote interface. This manual is written in Chinese.

What's inside

• Product Overview
• Front Panel Overview
• Rear Panel Overview
• Installation and Wiring
• Programming and Remote Interface
• Protection Features
• Output Control

Specifications

Frequently asked questions

What safety steps must be taken before turning on the power supply?

All safety precautions listed in the manual must be observed and all connections must be made before applying power.

How do you enable or disable the output of the N5700 series?

Press the OUT ON button to toggle the output; after an over‑current event, press OUT ON again to reset and re‑enable the output.
