ABB Low Voltage Process Performance Motors Catalog March 2016

This catalog details ABB's low voltage process performance motors, covering sizes from 63 to 450 and power outputs from 0.09 to 1000 kW.

Brand: ABB
Category: Motor
Document type: Product Leaflet
Language: English
Pages: 138
File format: PDF
File size: 24.2 MB
Published: 15 October, 2026
Updated: 15 October, 2026
MD5 checksum: AF965A2DBF6A60A7B6821BCCF36C6A96
PDF: ABB Low Voltage Process Performance Motors Catalog March 2016 PDF

About this manual

Published in March 2016, this document serves as a comprehensive guide for ABB's Low Voltage Process Performance Motors (document number 9AKK105944 EN). It covers the full range of sizes from 63 to 450 and power outputs ranging from 0.09 kW to 1000 kW.

What's inside

Mounting arrangements
Cooling methods
Degrees of protection: IP code/IK code
Insulation classes
Voltage and frequency
Surface treatment
Cast iron motors
Ordering information
Rating plates
Technical data

Specifications

Motor Sizes	63 to 450
Power Output Range	0.09 to 1000 kW
Efficiency Classes Covered	IE1, IE2, IE3, IE4
Standard for Efficiency Classes	IEC/EN 60034-30-1: 2014
Test Method Standard	IEC 60034-2-1 edition 2.0, 2014-06

Frequently asked questions

Which efficiency classes does ABB offer for these motors?

ABB offers a full range in IE2 and IE3 motors, with additional availability of IE4 motors.

What standard defines the International Efficiency (IE) classes?

The efficiency levels are defined by IEC/EN 60034-30-1: 2014.

What is the power range covered by this catalog?

The document covers a power output range from 0.09 kW to 1000 kW.
