This manual provides detailed hardware specifications and technical data for various ACS880 drive modules and packages, including ACS880-01, -04, -07, -17…
This document serves as a comprehensive hardware manual for the ABB ACS880 drive series. It covers a wide range of drive modules and packages, specifically detailing the hardware specifications for models such as the ACS880-01, ACS880-04 (200 to 710 kW), ACS880-07 (45 to 2800 kW), ACS880-17, and ACS880-37. The manual also includes information on inverter modules and units like the ACS880-104 and ACS880-107. This manual is written in Japanese.
| ACS880-04 Power Range | 200 to 710 kW, 300 to 700 hp |
|---|---|
| ACS880-04XT Power Range | 500 to 1200 kW |
| ACS880-07 Power Range (Standard) | 45 to 710 kW, 50 to 700 hp |
| ACS880-07 Power Range (High) | 560 to 2800 kW |
| Document Revision | Rev P |
| Publication Date | June 27, 2016 |
Yes, there is a specific hardware manual for the ACS880-04XT drive module packages.
The primary control program firmware manual is listed as a separate document with part number 3AUA0000085967.
