MR-E Super is a Mitsubishi general AC servo system with high performance and ease of use, reducing workload. It has high-precision positioning, high responsiveness, international standards and other features.
This manual provides comprehensive guidance for Mitsubishi MR‑E Super servo systems, including high‑performance servo motors (HF‑KE, HF‑SE series) and MR‑E series amplifiers. It details safety precautions, installation steps, wiring diagrams, and configuration procedures for both position and speed control modes.
The document also lists technical specifications such as encoder resolution, rated power, torque, and environmental limits, and explains how to connect optional accessories like regeneration modules, emergency stops, and monitoring interfaces. It includes troubleshooting tips and maintenance recommendations to ensure reliable operation in industrial applications. This manual is written in Chinese.
| Encoder resolution | 131072 pulses per revolution |
|---|---|
| Rated output power (HF‑KE13) | 0.1 kW |
| Rated torque (HF‑KE13) | 0.32 Nm |
| Maximum speed | 4500 rpm |
| Operating temperature range | 0 °C to 40 °C (storage –15 °C to 70 °C) |
For single‑phase operation the power supply must be connected to terminals L1 and L2; L3 must not be connected.
The servo motor is supplied with a magnetic brake, but the brake may only be used when the servo is in the OFF state.
The load inertia should be less than 15 times the motor's own inertia.
