The AirLive WMU-6000FS is an ultra‑slim portable wireless AP storage device designed for small‑office and home‑office use. It combines a 2.5‑inch hard‑disk drive with Wi‑Fi and Ethernet connectivity, allowing users to share files wirelessly or via a wired network.
This manual covers hardware overview, installation of the hard drive, wiring, wireless and wired network setup, file‑sharing methods (Windows network places, FTP, UPnP), configuration wizards, disk management, advanced functions such as firmware upgrade and reset, printer‑server setup for various operating systems, and troubleshooting tips.
| IDE controller | Ultra DMA 133 |
|---|---|
| Hard‑disk support | 2.5‑inch IDE HDD |
| File system support | FAT, FAT32, Ext2, read‑only NTFS |
| FTP server | Built‑in |
| USB host | USB 2.0 |
| Wireless data rates | Up to 54 Mbps (802.11g), up to 11 Mbps (802.11b) |
| Power supply | 5 V / 3 A |
| Encryption | 64/128‑bit WEP, WPA (TKIP/AES) |
| Authentication | 802.1X |
Press the Shutdown and Backup buttons simultaneously for over 6 seconds to reset the system to factory default settings.
Press the Backup button for more than 4 seconds to copy data from the USB device to the HDD.
It supports 6/12/18/24/36/48/54 Mbps in 802.11g mode and 1/2/5.5/11 Mbps in 802.11b mode.
