GBT GA-8IR533 P4 Titans DDR Motherboard Installation Guide

GA-8IR533 motherboard supports AGP 4X(1.5V), does not support AGP 2X(3.3V), if using AGP 2X (3.3V) card, the motherboard components will be burned.

GBT GA-8IR533 P4 Titans DDR Motherboard Installation Guide - cover page
Brand
GA-8IR533系列
Category
Other
Document type
Installation Guide
Language
Chinese
Pages
79
File format
PDF
File size
2.7 MB
Updated
30 September, 2023
MD5 checksum
6113269E337AA65CA459A45817F74971
PDF
GBT GA-8IR533 P4 Titans DDR Motherboard Installation Guide PDF

About this manual

This guide provides step‑by‑step instructions for installing the GA‑8IR533 series P4 Titans DDR motherboard. It begins with safety precautions, then details CPU, memory and interface‑card installation, connector wiring, and BIOS configuration.

Additional sections cover power‑saving settings, technical reference data such as FCC compliance, and an appendix with part numbers and support information. This manual is written in Chinese.

What's inside

  • Safety Precautions
  • CPU Installation
  • Memory Module Installation
  • Interface Card Installation
  • Power and Front‑Panel Connector Wiring
  • BIOS Configuration
  • Power‑Saving Settings
  • Technical Reference Documents
  • Appendix

Specifications

Model NumberGA-8IRS33
FCC ClassificationClass B Digital Device
